Hatch Hives

Chiller&Heater Thermal Control

Protective Devices:missing phase and undervoltagephase dislocation,compressor overload, and water pump overload protection etc.lt canalarm and display faults at any time.
Microcomputer temperature control system: temperature controllable range +5°C to+ 35°C, accuracy 0.1°C
Air-Cooled condenser:dense structure, small size exchangearge heat and save water.

Technical Parameter

Model No	Compressor Power		Voltage (V)	Cooling Capacity (KW)	Heating Capacity (KW)	Weight (KG)	Size (mm)	Inlet/Outlet (mm/inch)	Refrigerant	Cooling Type
Model No	(KW)	(HP)	Voltage (V)	Cooling Capacity (KW)	Heating Capacity (KW)	Weight (KG)	Size (mm)	Inlet/Outlet (mm/inch)	Refrigerant	Cooling Type
ZH-HC2	1.5	2	380	7.8	10	145	1000×280×550	Φ50 (1.5")	R22	Air Cooling
ZH-HC5	3.8	5	380	13	16	195	750×750×1050	Φ50 (1.5")	R22	Air Cooling
ZH-HC10	7.7	10	380	26	30	450	1450×730×1050	Φ50 (1.5")	R22	Air Cooling
ZH-HC15	11.3	15	380	39	44	670	1600×800×1600	Φ63 (2")	R22	Air Cooling
ZH-HC20	15	20	380	50	58	720	1860×1000×2120	Φ90 (3")	R22	Air Cooling
ZH-HC25	19	25	380	65	72	860	2100×1100×2180	Φ90 (3")	R22	Air Cooling
